Double Polybac 75 M drinker with patented strip rim and fastening support
Available in 2 versions 30 M and 75 M
Made from rot-proof rotomolded polyethylene, these large capacity drinkers are fitted with the La Gée float valve 32 l/mn and a 33/42 through wall plug for quick cleaning and emptying.
The mechanism is protected by a cast aluminium or stainless steel sheet housing. Wall trough supports are factory fitted with a water inlet on the wall side. Ideally operates on pressure range from 3 to 4 bars.
They are designed with a wide heavy-duty bowl suited to animal morphology (cattle, horses, goats).
Designed with a wide bowl with a patented strip rim offering durability, facilitating cleaning, and increasing the water surface available.
Can be wall-mounted using the galvanised steel fastening support.
Delivered with fastening support. Stainless steel housing to protect the float valve.
Delivered without fastening support.
- Material
- rotomolded polyethylene resin
- Length
- 995 mm
- Width
- 495 mm
- Height
- 298 mm
- Capacity
- 75 l
- Model
- 75 M
- Type
- strip rim
- Pressure
- network
- Drinker
- Polybac M
- System
- constant level
- Mechanism
- float valve tap
- Fastening
- wall
- Device
- non-heating
- Connection diameter
- 1/2" (15/21 mm) - male wall-side
- Packaging
- Paddle
- Flow rate
- 1 to 32 l/min
- Sales unit
- Unit
- Float valve
- Pressure network in polyamide white (P1138310)
- Drain plug
- Through-wall drain plug 33/42 mm
